Symbol library for LayOut

$18.00

Save valuable time with our library of French architectural symbols for LayOut 2017 to 2021!

Library: Sent automatically with your order confirmation. To be downloaded directly.

No technical support will be provided with the product.

Symbol library for LayOut

NO MORE NEED TO SEARCH IN YOUR FILES FOR SYMBOLS, CARTOUCHES OR HATCHINGS… WE HAVE MADE A LIBRARY OF FRENCH SYMBOLS TO MAKE YOUR WORK EASIER!

The library contains:

1 page showing different types of cartridges
1 page containing identification and marker bubbles 💬
1 page containing different types of features and dimension styles ✏️
1 page of predefined parts list
1 page of symbols for electrical drawings💡
1 page of electrical legend blocks🔌
1 page of door symbols🚪
1 page of hatchings📏
1 page of miscellaneous symbols for plans📍
2 pages of characters with varying scales👯♀️
6 pages of vegetation 🌱
6 pages of plumbing symbols 🚰

An explanation video for the installation is available here :

GET MY LIBRARY
